Proaim Powermatic Scissor Pro 17ft Telescopic Camera Jib Crane w New Remote Controller (Dampening & Speed Control)

Payload- 15kg / 33lb

CAD 4,640.00 - CAD 4,640.00

CAD 4,640.00

CAD 4,640.00 - CAD 4,640.00

CAD 4,640.00

SKU : JB-SCSR-02

Qty

CLICK To Discover All Scissor Cranes

EXPLORE All Available Crane Options

Next Step in the Evolution of Camera Jib!

Quickly Moves In/Out of a Shot. Maneuvers into Inaccessible Areas – Smoothly & Silently.

01.

Thoughtful Engineering

Proaim Powermatic Scissor telescopic camera crane lets you easily capture creative shots usually done with high-end and expensive Technocranes.
Extending the scissor arm puts the camera right where you need it. The flexible motion allows the arm to open 17’ out and then retract back in.
High-grade Aluminum Crane Frame is lightweight & durable enough to hold 3-Axis Camera Gimbals with a maximum payload of 15kg / 33lb.
The high-speed special 70 steel bearings ensure outstanding durability & strength while providing smooth soundless movement every time you extend or retract.
It is perfect for tight indoor spaces as well as on-location shoots. It even fits into a private vehicle.

02.

Effortless Operation

The Powermatic Scissor allows you to achieve fluid movements of extreme precision without any difficulty.
Steady Fluid Head ensures perfect alignment of your 3-Axis Gimbal on Scissor Crane.
Tilt Lock allows you to fix the jib’s tilt angle to get linear tracking shots.
Pan Lock enables locking the jib’s pan movement for achieving high/low angle shots.
LCD Mounting Arm helps in attaching an LCD monitor for better viewing of shots; the arm can be mounted left/right as per your requirement.

03.

Fully-Featured Controller Kit

The new & improved Remote Controller Kit, lets you efficiently control the speed and damping of your jib rendering enhanced control & precision.
The kit comes equipped with a Remote Control and a Controller Box which has a battery plate; it adapts a 15V V-Mount Battery to power and drives the jib arm smoothly.
The included Spiral Cable attaches the Controller Box to the Remote Controller, thus powering the latter to regulate the movements of the jib.
The highly-functional Controller Kit facilitates features like Damping Adjustment, Speed Control & Direction Control etc.

04.

Precisely Controlled Moves

With these super-functional additional features, the controller is an ideal choice for your Scissor Jib Crane

Retraction/Expansion

The forward/reverse buttons let you conveniently push out and pull in the jib arm.

Speed Controller

The speed dial, as the name suggests, lets you control the speed intensity of the jib movements.

Damping Adjustment

The damping adjustment dial lets you control the level of damping and facilitate smooth, stabilized movements as the jib expands & retracts.

Direction Control

The direction button lets you lock the direction in which you want your jib to move- forward or reverse.

05.

Simplified Transport

The Complete Crane System fits in a Flight Case for easy storage. This storage case is easy to carry with you to different sets and locations.

See how the Scissor Pro Crane Works

Scissor Crane Specifications

Construction

High-Grade CNC Aluminum

Payload

15kg / 33lb

Total No. of High-Speed Steel Bearings

70

Total Length Extended

17feet / 5.2m

Total Length Closed

3.3feet

Extended Height from Ground

17.4feet / 5.3m

Closed Height from Ground

6.3feet

Crane Pan Lock

Yes

Crane Tilt Lock

Yes

Self‐balance Weight (Extended/Collapsed)

24kg / 53lb

Maximum Speed

Forward Speed of Scissor Jib in Second:- 12 sec
Reverse Speed of Scissor Jib in Second:- 11 sec

Minimum Speed

Forward Speed of Scissor Jib in Second:- 25 sec
Reverse Speed of Scissor Jib in Second:- 21 sec

Power Source

V‐Mount Battery (Not Included)

Battery Runtime

Depend on battery

Dimensions

Weight of Scissor Jib

33kg / 73lb

Product Weight (Without Packing)

41kg / 90.38lb

Product Volumetric Weight (With Packing)

73.26kg / 161.51lb

Motor Specifications

IP44 Protection

Certified

Rated Voltage

12V -15V DC

Rated Power

60W

Nominal Current

10A DC

Maximum Thrust Force

1000N

Maximum Pulling Force

1000N

Travelling Speed

36mm/sec

Noise

<55dB

Vibration

Not Noticeable

Remote Controller Kit Specifications

Construction

High Grade Aluminum

Battery Plate

V‐mount

Compatible Power Source

Option:‐ 15V AC Adapter (Not Included)
V‐Mount Battery (Not Included)

Dimensions

Weight of Remote Controller Kit

2.4kg / 5.29lb

In the Box

17ft Powermatic Scissor Jib with Gimbal Fluid Head
3 x Guide Rods
Weight Rod
Hub Locking knob
Monitor Arm
Speed Controller Remote
Controller Spiral cable
2 x Weight Closers
Ronin Controller Bracket
15Ac Adapter
Controller Box with Battery plate
HDMI Male to Male Wire
BNC Wire
2 x Fuse
Female to Female Connector
Female to Female Connector
Spanner (Size: 13mm)
50 Piece Cable Tie
Flight Case

User Manual

Proaim Powermatic Scissor Pro 17ft Telescopic Camera Jib Crane w New Remote Controller

Guaranteed Fast Delivery
For all orders

Quick and Efficient
Customer service

Easy Returns
Up to 30 days

1-Year Warranty
On All Products

Q&A

Ask a Question

I purchase a scissor crane. Do you have an instructional video on how to put it together?

Below is the video of how to assemble Proaim Powermatic Scissor 17ft Telescopic Camera Jib Crane JB-SCSR-00:
https://www.youtube.com/watch?v=cbURj6fWOK8
Can I please order the new precise remote for my scissor jib? The old remote is really hard to work with.

Yes, you can purchase the new remote for Scissor Jib, that is Proaim Upgraded Controller Kit for Powermatic Scissor Camera Jib Crane JB-SCSR-UK. Here is the link for your reference:
https://www.proaim.ca/products/proaim-upgraded-controller-kit-for-powermatic-scissor-camera-jib-crane

With the help of this remote, you can control the Retraction/Expansion, Speed, Damping, and Direction.
